Bowers XT Analogue Bore Gauge - Metric
Free Tyre Inflator (Spend £1000+)
- Range 2-300mm (0.080"-12")
- Blind bore measurement
- Supplied in a fitted wooden case
SKU
BG-XTA-X-M
The Bowers XTA Metric Analogue Bore Gauge range provides internal measurement across 2 mm to 300 mm. The mechanical travel removes the need to change measuring anvils. Available in sizes from 20–300 mm, with two-point contact in smaller ranges and three-point contact from 35 mm upward. XT measuring heads and setting rings with UKAS certification included.
XT Analogue Micro Bore Gauge Overview & Quick Demo | Bowers Group
Key Features
- Range 2-300mm (0.080"-12")
- 2-6mm 2 point / 6-300mm 3 point measurement
- Graduation 2-6mm: 0.001mm, 6-300mm: 0.005mm
- Tungsten carbide measuring faces on all 3-point heads from 12.5mm
- Blind bore measurement from 2mm-6mm and above 12.5mm (0.500")
- Extensions available above 6mm for deep hole measurement
- Ratchet stop to ensure consistent measurement
- Setting rings included with individual instruments and sets
- UKAS certificates supplied as standard with all setting rings
- UKAS certificate supplied as standard with all XT mechanical micrometers
- Serial number on all gauges
- Bore gauges manufactured according to DIN 863, part 4
- Supplied in fitted wooden case
Product Range
- Bowers XTA20M XT Analogue Bore Gauge, 20-25mm
- Bowers XTA25M XT Analogue Bore Gauge, 25-35mm
- Bowers XTA35M XT Analogue Bore Gauge, 35-50mm
- Bowers XTA50M XT Analogue Bore Gauge, 50-65mm
- Bowers XTA65M XT Analogue Bore Gauge, 65-80mm
- Bowers XTA80M XT Analogue Bore Gauge, 80-100mm
- Bowers XTA100M XT Analogue Bore Gauge, 100-125mm
- Bowers XTA125M XT Analogue Bore Gauge, 125-150mm
- Bowers XTA150M XT Analogue Bore Gauge, 150-175mm
- Bowers XTA175M XT Analogue Bore Gauge, 175-200mm
- Bowers XTA200M XT Analogue Bore Gauge, 200-225mm
- Bowers XTA225M XT Analogue Bore Gauge, 225-250mm
- Bowers XTA250M XT Analogue Bore Gauge, 250-275mm
- Bowers XTA275M XT Analogue Bore Gauge, 275-300mm
Offers
Free Tyre Inflator (Spend £1000+)
Worth £29.99. Automatically adds to your basket when the total exceeds £1000+ (ex VAT). Limited Stock. More details here.
Technical Information
Specification
| Range (mm) | Accuracy (mm) | Depth (mm) | Setting Ring (mm) | |
|---|---|---|---|---|
| XTA20M | 20-25 | 0.004 | 66 | 20.00 |
| XTA100M | 100-125 | 0.006 | 115 | 125.00 |
| XTA125M | 125-150 | 0.006 | 115 | 125.00 |
| XTA150M | 150-175 | 0.007 | 115 | 175.00 |
| XTA175M | 175-200 | 0.007 | 115 | 175.00 |
| XTA200M | 200-225 | 0.008 | 118 | 225.00 |
| XTA225M | 225-250 | 0.008 | 118 | 225.00 |
| XTA250M | 250-275 | 0.009 | 118 | 275.00 |
| XTA25M | 25-35 | 0.004 | 66 | 35.00 |
| XTA275M | 275-300 | 0.009 | 118 | 275.00 |
| XTA35M | 35-50 | 0.004 | 80 | 35.00 |
| XTA50M | 50-65 | 0.005 | 80 | 65.00 |
| XTA65M | 65-80 | 0.005 | 80 | 65.00 |
| XTA80M | 80-100 | 0.005 | 100 | 80.00 |
