Mark-10 G1098 Loop Tack Fixture, 5/16-18F

The Mark-10 G1097 is designed for tack force testing of pressure-sensitive adhesives, in conformance with ASTM D6195 and related standards. Thread size 5/16-18F. A looped sample is loaded onto the test strip, and the closed end of the loop is secured by an upper grip (not included - suggested model: G1008).

The test strip may be indexed in three positions, allowing for three tests to be performed between cleaning cycles. The strip is secured and released by a lever-operated clamp.  An additional set of three test strips is available here.

Key Features

• Designed for loop tack force testing
• Quick-change mechanism for test strips
• Conforms to ASTM D6195
• Capacity: 100 lbF [500 N]
• Weight (including one test strip): 1.1 lb [0.5 kg]
• Test strip material: T304 SS, per ASTM A666
