Sauermann Kimo K-Si-PM3 Manometer
Description
The palm-sized Sauermann Kimo K-Si-PM3 digital differential pressure manometer easily measures pressure.
Full overview of Sauermann’s new easy-to-use HVACR Instrument Range
Key Features
- Backlit LCD screen
- Magnetic backing for easy fixing
- Carrying bag
- Measuring range: -150 to +150 hPa (-60 to 60 inH2O)
- Air velocity and airflow with Pitot tube (optional)
What's Included?
- 1 Digital Differential Pressure Manometer
- 2 Clear tubes Ø4x6 mm, 1 m (39.37') length
- 1 Certificate of conformity
- 1 Quick Start Guide
- 3 Alkaline batteries LR03 AAA 1.5 V
- 1 Carrying bag
Si-PM3: draft measurement to evaluate the draft at the exit of combustion boilers
Si-PM3: pressure measurement of the gas inlet valve of a combustion boiler
Downloads
Tech Specs
| MEASURE DETAILS | |
|---|---|
| Units | inH₂O, Pa, mbar, hPa, mmH₂O, psi |
| MEASURING RANGES | |
| Pressure | -150.00 hPa ... 150.00 hPa |
| Airflow | 0.00 m³/h ... 9999.00 m³/h |
| Air velocity | 2.00 m/s ... 80.00 m/s |
| TECHNICAL DETAILS | |
| Parameters | Air velocity Airflow Differential pressure |
| Displays | 2-line display |
| IP Protection | IP 40 |
| Battery Life | 170 hours |
| Standards | RoHS II 2011/65/EU (EU)2015/863 UKCA 2012/19/UE DEEE 2014/53/EU RED |
| Wireless Connection | 1 |
| Power Supply | 3 alkaline batteries LR03 AAA 1.5 V |
| Protective Cover | No |
| Interchangeable Module | No |
| INSTRUMENT DIMENSIONS | |
| Length | 2 3/4 inches 70 mm |
| Width | 1 5/16 inches 33 mm |
| Height | 5 9/16 inches 141 mm |
| Weight | 7 pounds 200 g |
| OPERATING TEMPERATURE | |
| Min | 0.00 °C |
| Max | 50.00 °C |
| STORAGE TEMPERATURE | |
| Min | -20.00 °C |
| Max | 70.00 °C |
0 Reviews
Overall Rating
Additional Information
| SKU | K-Si-PM3 |
|---|---|
| Manufacturer Part Code | Si-PM3 |
