Testo 340 Flue Gas Analyser - NO₂/ NOx Kit
The Testo 340 Flue Gas Analyser - NO₂/ NOx Kit includes the following products:
- Testo 340 Flue Gas Analyser with O₂, CO, NO and NO₂ Sensors and an Integrated Bluetooth Module
- Testo 340 Carry Case
- Switching Power Supply 6, 3VDC 2A
- Carry Strap
***Please note that this product is customisable. If you require customisation please call our Sales Team on 01642 931 0167. Any customised products are non-refundable unless found faulty. See terms and condition***
For further information regarding the Testo 340 Flue Gas Analyser, please see the following description.
Testo 340 Flue Gas Analyser Description
As mentioned above, the Testo 340 Flue Gas Analyser included in this kit is fitted with oxygen (O₂), carbon monoxide (CO), nitric oxide (NO) and nitrogen dioxide (NO₂) sensors. It is capable of measuring the concentration of these gases within the following ranges:
- O₂: 0 to 25 vol.%
- CO (H₂ compensated): 0 to 10 000ppm
- NO: 0 to 4000ppm
- NO₂: 0 to 500ppm
The Testo 340 Flue Gas Analyser is also capable of calculating pressure difference and air flow measurements for mass flow calculations.
The Testo 340 Flue Gas Analyser’s multiple gas sensors and extended measuring ranges make it suitable for a variety of applications including industrial flue gas analysis, industrial emissions measurements, verifying the installation of firing plants and energy production systems. It is also suitable for use in international service operations. For further information regarding the Testo 340 Flue Gas Analyser’s applications please see the ‘Applications’ section.
Contributing to the versatility of this instrument is its extended measuring range which makes it suitable for use in areas with high concentrations of gases. The extended measurement range (thinning) is automatically engaged when high levels of gas are detected; this means that the demands on the Testo 340 Flue Gas Analyser’s sensors are the same as when the Testo 340 is used in areas with low gas concentrations.
Each of the integrated sensors has been TÜV tested and accuracy checked in accordance with the standard EN 50379 Part 2. These sensors are pre-calibrated ensuring that cells may be changed quickly and easily in the field, adding to the versatility of the Testo 340 Flue Gas Analyser.
The reliability and functionality of the Testo 340 Flue Gas Analyser are preserved via the inclusion of an integrated condensation trap and an integrated automatically controlled measurement gas pump. The condensation trap prevents the build-up of concentrate in the gas sensor and will notify the user when the trap requires emptying. The integrated automatic gas pump maintains a constant flow in the event of negative pressure or overpressure between -200 to +50 mbar.
The Testo 340 Flue Gas Analyser’s compact and robust design also preserves its longevity and adds to its suitability for industrial environments. The design of the Testo 340 Flue Gas Analyser enables OPTIONAL probes to be connected quickly and easily allowing the user to adapt the Testo 340 to suit the application. These OPTIONAL probes can be used interchangeably as the probe shaft is attached to the probe handle and then connected to the Testo 340.
When used with Testo’s easyEmissions Software (NOT included), the user is able to create customer-specific and application-specific measurement protocols, again enabling him/her to tailor the Testo 340 Flue Gas Analyser to suit the application. The Testo easyEmissions Software is designed for reading, editing, archiving and managing data and, when the Testo 340 Flue Gas Analyser is connected to this software program via a Bluetooth or USB interface, it can be used to perform online measurements. During online measurements, the user is able to view real-time values via his/her PC/ laptop while the measurement is ongoing.
Another advantage of the Testo 340 Flue Gas Analyser’s Bluetooth capabilities is that it can be operated remotely via the user’s smartphone or tablet with the free Testo App installed. This app can also be used to view data in a graph or table, as well as send information to print via Bluetooth and using a compatible Testo Printer.
It is also possible to send measurements to print via Bluetooth directly from the Testo 340 Flue Gas Analyser (a compatible Testo Bluetooth Printer is required). Alternatively, data can be sent to print via an infrared interface and using a Testo Infrared Printer.
The Testo 340 Flue Gas Analyser is a flexible, durable, reliable gas detector and analyser optimised for industrial applications.
Testo 340 Flue Gas Analyser Key Features
- Fitted with O₂, CO, NO and NO₂ sensors
- O₂: 0 to 25 vol.%
- CO (H₂ compensated): 0 to 10 000ppm
- NO: 0 to 4000ppm
- NO₂: 0 to 500ppm
- Calculate pressure difference and air flow measurements for mass flow calculations
- Suitable for industrial flue gas analysis, industrial emissions calculations and verifying the installation of firing plants and energy production systems
- Suitable for use within international service operations
- Extended measuring range ensures the Testo 340 is suitable for use in areas with high gas concentrations
- Extended measuring range (thinning) is automatically engaged when high gas levels are detected
- Extended measuring range ensures that there are no extra demands placed on the gas sensors in environments with high gas concentrations
- Each gas sensor has been TÜV tested and checked in accordance with the standard EN 50379 Part 2
- Pre-calibrated sensors enable cells to be changed quickly and easily in the field
- Integrated condensation trap: alerts the user when it needs emptying
- Integrated automatically controlled measurement gas pump maintains a constant flow in negative pressure or overpressure between -200 to +50 mbar
- Compact and robust design
- OPTIONAL probes can be connected to the analyser quickly and easily
- Tailor the analyser to suit various applications via the addition of OPTIONAL probes
- Compatible with the Testo easyEmissions Software (NOT included)
- Create customer-specific and application-specific measurement protocols using the aforementioned software
- Take online measurements when the analyser is connected to the Testo easyEmissions Software via Bluetooth or USB
- When conducting online measurements, the user can view real-time values via a PC/ laptop while the measurement is ongoing
- Integrated Bluetooth module
- Can be operated via a smartphone or tablet with the free Testo App installed using the Bluetooth interface
- Send data to print via Bluetooth (Testo Bluetooth Printer required)
- Send data to print via an infrared interface (Testo Infrared Printer required)
- A flexible, durable and reliable gas detector and analyser optimised for industrial applications
Applications
Flue Gas Analysis for Thermal Manufacturing Processes
The Testo 340 Flue Gas Analyser can be used to optimise processes and save fuel. In addition to optimising combustion systems and monitoring processes, the Testo 340 Flue Gas Analyser can be used for emission control applications, such as verifying that flue gas emissions are within the permissible limits and that emission instruments are functioning correctly.
Service Measurements of Industrial Engines
As this Testo 340 Flue Gas Analyser includes sensors for NO and NO₂, it is capable of taking measurements for each of these gases separately allowing the user to determine a correct NOx value. It is possible to view NO and NO₂ values simultaneously along with other gas parameters relevant to industrial engines.
As the Testo 340 Flue Gas Analyser automatically dilutes the CO sensor when unexpectedly high concentrations of this gas are detected (up to 50 000 ppm), the user is able to measure industrial engines with undefined engine conditions without damaging the sensor.
Finally, as the Testo 340 Flue Gas Analyser can be used with an array of OPTIONAL, highly heat-resistant, interchangeable probes, it can be adapted to suit the industrial engine that is under investigation.
Service Measurements of Industrial Burners
The Testo 340 Flue Gas Analyser can be used to check that industrial burners are functioning correctly and efficiently and are compliant with environmental regulations. It is of particular use during maintenance and troubleshooting applications and may be used to commission safe and efficient burners.
The Testo 340 Flue Gas Analyser’s extended measurement range and rugged design make it suitable for inspecting industrial burners, as does its simple-to-use interface with an array of typical fuel options, sequences of flue gas parameters, and pre-configured settings for each application. The user is guided through each measurement by tips on the Testo 340 Flue Gas Analyser’s display.
What’s Included?
- Testo 340 Flue Gas Analyser with O₂, CO, NO and NO₂ Sensors and an Integrated Bluetooth module
- Testo 340 Carry Case
- Switching Power Supply 6, 3VDC 2A
- Carry Strap
Testo 340 Flue Gas Analyser Technical Specifications
| Differential Pressure - Piezoresistive | |
| Measuring range | -200 to 200 hPa |
| Accuracy | ±0.5 hPa (-49.9 to 49.9 hPa) |
| ±1.5 % of mv (Remaining Range) | |
| Resolution | 0.1 hPa |
| Absolute Pressure | |
| Measuring range | +600 to +1150 hPa |
| Accuracy | ±10 hPa |
| Resolution | 1 hPa |
| Flue gas O₂ | |
| Measuring range | 0 to 25 Vol.% |
| Accuracy | ±0.2 Vol.% |
| Resolution | 0.01 Vol.% |
| Reaction time t₉₀ | < 20 s |
| Flue gas CO (with H₂-compensation) | |
| Measuring range | 0 to 10000ppm |
| Accuracy | ±10 ppm or ±10 % of mv (0 to 200 ppm) |
| ±20 ppm or ±5 % of mv (201 to 2000 ppm) | |
| ±10 % of mv (2001 to 10000 ppm) | |
| Resolution | 1 ppm |
| Reaction time t₉₀ | < 40 s |
| Flue gas NO | |
| Measuring range | 0 to 4000 ppm |
| Accuracy | ±5 ppm (0 to 99 ppm) |
| ±5 % of mv (100 to 1999 ppm) | |
| ±10 % of mv (2000 to 4000 ppm) | |
| Resolution | 1 ppm |
| Reaction time t₉₀ | < 30 s |
| Flue gas NO₂ | |
| Measuring range | 0 to 500 ppm |
| Accuracy | ±10 ppm (0 to 199 ppm) |
| ±5 % of mv (Remaining Range) | |
| Resolution | 0.1 ppm |
| Reaction time t₉₀ | < 40 s |
| Note | To avoid absorption, a maximum measurement duration of 2 hours should not be exceeded. |
| Differential Pressure flue gas Draught - Piezoresistive | |
| Measuring range | -40 to +40 hPa |
| Accuracy | ±0.03 hPa (-2.99 to +2.99 hPa) |
| ±1.5 % of mv (Remaining Range) | |
| Resolution | 0.01 hPa |
| Temperature | |
| Measuring range | -40 to +1200 °C |
| Accuracy | ±0.5 °C (0 to +99 °C) |
| ±0.5 % of mv (Remaining Range) | |
| Resolution | 0.1 °C |
| Flue gas degree of effectivity, Eta (calculated) | |
| Measuring range | 0 to 120 % |
| Resolution | 0.1 % |
| Flue gas loss (calculated) | |
| Measuring range | 0 to 99.9 % |
| Resolution | 0.1 % |
| Flue gas dewpoint (calculated) | |
| Measuring range | 0 to 99.9 °Ctd |
| Resolution | 0.1 °Ctd |
| Flue gas CO₂ calculation (calculated from O₂) | |
| Measuring range | 0 to CO₂ max |
| Accuracy | ±0.2 Vol.% |
| Resolution | 0.1 Vol.% |
| Reaction time t₉₀ | < 40 s |
| General Technical Data | |
| Weight | 960 g |
| Dimensions | 283 x 103 x 65 mm |
| Operating temperature | -5 to +50 °C |
| Product-/housing material | TPE PC |
| Protection class | IP40 |
| Product colour | Black |
| Connectable probes | 1 x flue gas probe; 1 x temperature probe; 1 x differential pressure |
| Battery life | > 6h (Pumpe an, Displaybeleuchtung aus, bei 20°C) / > 6h (Pumpe an, Displaybeleuchtung aus, bei 20°C) |
| Display type | graphic Display |
| Display size | 160 x 240 pixels |
| Display function | Graphic display |
| Power supply | Battery block 3.7 V / 2.4 Ah, Mains unit 6.3 V / 2 A |
| Max. neg. press./flue gas | -200 mbar |
| Max. pos. press./flue gas | 50 mbar |
| User-defined fuels | 10 user-defined fuels incl. test gas as fuel |
| Hose length | max. 7.8 m (corresponds to two probe hose extensions) |
| Pump flow | 0.6 l/min (regulated) |
| Maximum memory | 100 folders |
| Storage per folder | Max. 10 sites |
| Storage per site | Max. 200 logs |
| Miscellaneous | The max. number of logs is determined by the number of folders or sites |
| Interface | Bluetooth®; USB; IR/IRDA interface; gas outlet; Mains connection; probe input/ probe inputs; Differential Pressure |
| Storage temperature | -20 to +50 °C |
| SKU | 05639350 |
|---|---|
| Manufacturer Part Code | 0563 9350 |
