FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger
The FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger is optimised for monitoring the storage temperature of vaccines. It includes a probe housed in glycol bottle which mimics the thermal response of vaccines, providing the user with a more accurate representation of their temperature during refrigeration.
The FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger has a measurement range of -40°C to +125°C and a resolution of 0.1°C. Data is displayed on the high-contrast LCD with a four-digit display function. Users can cycle through the current, minimum, and maximum measurements at the touch of a button.
Over 32 000 readings can be stored to the FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger. The user can set the logging rate between 1s and 12hrs. Furthermore, it can be configured for immediate, delayed or push-to-start recording. Its lithium battery provides a logging life of approximately two years. In addition to this, the FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger supports user-programmable alarm thresholds.
The FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger is easy to set up using the free EasyLog 21CFR Software. Please see the video below for more information.
Moreover, recorded data can be downloaded to a PC via a USB port, where it can be viewed, graphed, printed, and exported using FilesThruTheAir’s EasyLog 21 CFR Software. The data is encrypted and offers full audit tracking to comply with 21CFR Part 11.
The FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger is a reliable and simple-to-use temperature data logger specifically designed for monitoring vaccines.
FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger Key Features
- Optimised for monitoring the storage temperature of vaccines
- Probe housed in a glycol bottle mimics the thermal response of vaccines
- Temperature range: -40°C to +125°C
- Resolution: 0.1°C
- High-contrast LCD with a four-digit display function
- Cycle through the current, minimum, and maximum measurements at the touch of a button
- Store over 32 000 readings
- Set the logging rate between 1s and 12hrs
- Immediate, delayed or push-to-start recording
- Lithium battery provides a logging life of approximately 2 years
- User-programmable alarm thresholds
- Set up using the free EasyLog 21CFR Software
- Download data to a PC via USB
- View, graph, print, and export data using the EasyLog 21CFR Software
- Audit tracking to comply with 21CFR Part 11
- A reliable and simple-to-use temperature data logger specifically designed for monitoring vaccines
What’s Included?
- FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data
- Mounting Bracket
- Battery
- Temperature Calibration Certificate
FilesThruTheAir EL-21CFR-VAC Vaccine Temperature Data Logger Technical Specifications
| Measurement range | -40 to +125°C (-40 to +257°F) |
| Accuracy (logger error) | ±0.1°C (±0.2°F) |
| Resolution (display) | 0.5°C (1°F) |
| Resolution (data) | 0.1°C (0.2°F) |
| Logging rate | User selectable between 1 second & 12 hours |
| Operating temperature range | -35 to +80°C (-31 to +176°F) (data logger only) |
| Battery Life | 2 years (at 25°C and 1 minute logging rate, LCD on) |
| Readings | 32,510 |
| Dimensions | 135 x 24 x 21mm (5.31 x 0.94 x 0.82”) |
| SKU | EL-21CFR-VAC |
|---|---|
| Manufacturer Part Code | EL-21CFR-VAC |
