FLIR C3-X Compact Thermal Imaging Camera Front & Back

FLIR C3-X Compact Thermal Imaging Camera - Optional Wi-Fi

This pocket-sized infrared-imaging and visible-light imaging camera can be used to inspect buildings, HVAC/R, and electrical systems. The FLIR C3-X Compact Thermal Imaging Camera is a professional troubleshooting tool with an integrated LED torch, 3.5” touchscreen display, and optional Wi-Fi connectivity.

Thermal & Optical Imaging

The FLIR C3-X Compact Thermal Imaging Camera’s IR sensor has a resolution of 128 x 96px and thermal sensitivity of 70mK. It can detect and measure temperatures between -20°C and +300°C to an accuracy of ±3°C/3%.

Additionally, the FLIR C3-X includes a built-in 5MP digital camera. MSX® Imaging mode overlays details captured by the digital camera onto the corresponding thermal image, thereby improving the clarity of the picture and increasing the speed and ease with which the thermographer can identify the source of faults.

The C3-X also includes Visual, Infrared and Picture-in-Picture imaging modes, as well as four selectable thermal colour palettes: Iron, Grey, Rainbow and Rainbow HC.

Images can be saved to the camera’s onboard memory (capacity: up to 5000 images). They can be downloaded to a PC via a USB interface for analysis and organisation into reports using the thermographer’s preferred software, for example, FLIR Thermal Studio.

Ergonomic & Easy to Use

This small camera easily fits inside a pocket or crowded tool bag. It is rugged, having been drop-tested from 2m, and is resistant to dust and water ingress (IP54). Furthermore, the 3.5” touchscreen display and simple user interface ensure that it is easy to operate.

Optional Wi-Fi

Optional Wi-Fi provides FLIR Ignite™ Cloud Connectivity. Images can be uploaded to the FLIR Ignite™ Cloud for convenient storage, organisation and backup. Thermographers can add annotations to images to draw attention to and explain diagnosed issues. Moreover, these images can be easily and securely accessed: thermographers may send clients a password-protected link via email.

There are two versions: one with Wi-Fi and one without Wi-Fi. Please see the table below for further information.

SKU Wi-Fi
90501-0101 No
90501-0201 Yes

The FLIR C3-X Compact Thermal Imaging Camera is a small, simple-to-use infrared imager ideal for finding hot fuses, air leaks and plumbing issues.

FLIR C3-X Applications

Poultry Farmer's Barn Ventilation Report
Read how FLIR cameras helped identify how barn ventilation impacted chickens' health, welfare and farm profits!

Key Features

  • Pocket-sized infrared-imaging and visible-light camera
  • Inspect buildings, HVAC/R, and electrical systems
  • Professional troubleshooting tool
  • Integrated LED torch
  • 3.5” touchscreen display
  • OPTIONAL Wi-Fi
  • Two models available: one with Wi-Fi and one without Wi-Fi
  • IR sensor resolution: 128 x 96px
  • Thermal sensitivity: 70mK
  • Temperature range: -20°C to +300°C
  • Accuracy: ±3°C/3%
  • Built-in 5MP digital camera
  • MSX® imaging mode: overlays digital details onto thermal images
  • Visual imaging mode
  • Infrared imaging mode
  • Picture-in-Picture imaging mode
  • Four selectable thermal colour palettes: Iron, Grey, Rainbow and Rainbow HC
  • Onboard memory: capacity 5000 images
  • USB interface
  • Small: easily fits in a pocket or crowded tool bag
  • Drop-tested from 2m
  • IP54
  • Simple user-interface
  • OPTIONAL Wi-Fi provides FLIR Ignite™ Cloud Connectivity
  • Save images to the FLIR Ignite™ Cloud
  • Add annotations to images
  • Send clients a password-protected link via email
  • A small, simple-to-use infrared imager
  • Ideal for finding hot fuses, air leaks and plumbing issues

What Accessories Come with the FLIR C3-X?

  • Wrist Strap
  • Lanyard
  • USB Cable
  • Pouch
  • Printed Documentation

FLIR C- Series Thermal Camera Comparison

FLIR C3-X FLIR C5
IR sensor 128 × 96 (12,288 pixels) 160 × 120 (19,200 pixels)
Thermal sensitivity/NETD <70 mK
Field of view (FOV) 53.6° 54° × 42°
Temperature range
-20 to 300°C (-4 to 572°F)
-20 to 400°C (-4 to 752°F)
Minimum focus distance Thermal: 0.1 m (3.94 in)
MSX®: 0.3 m (11.8 in)
Image frequency 8.7 Hz
Focus Focus free
Spectral range 8–14 μm
Screen size 3.5 in
Digital camera  5 MP
Image modes
 Infrared image, Visual image, MSX, Picture-in-picture
Image adjustment
Automatic level and span, Manual level and span Automatic level and span, Manual level and span, 1-Touch level and span
Colour palettes
Iron, Grey, Rainbow, Rainbow HC Iron, Grey, Rainbow, Rainbow HC, Arctic, Lava

ITC Thermography Training

Get the most out of your thermal camera with an ITC course, learn how to conduct surveys and interpret and analyse valuable thermal information.



FLIR C3-X Compact Thermal Imaging Camera Technical Specifications

Overview C3-X
IR sensor 128 × 96 (12,288 pixels)
Thermal sensitivity/NETD <70 mK
Field of view (FOV) 53.6°
Minimum focus distance Thermal: 0.1 m (3.94 in)
MSX®: 0.3 m (11.8 in)
Image frequency 8.7 Hz
Focus Focus free
Spectral range 8–14 µm
Screen size 3.5 in
Digital camera 5 MP
Digital camera focus Fixed
Image Presentation
Image adjustment Automatic level and span
Manual level and span
Image modes Infrared image
Visual image
MSX (Embossed visual details on thermal image)
Picture-in-picture (IR area on visual image)
Gallery Thumbnails and custom folder structure
Colour palettes Iron
Grey
Rainbow
Rainbow HC
Auto orientation Yes
Touch screen Capacitive touch
Measurement & Analysis
Object temperature range -20 to 300°C (-4 to 572°F)
Accuracy 0 to 100°C (32 to 212°F): ±3°C (±5.5°F)
100 to 300°C (212 to 572°F): ±3%
[Ambient temp. 15 to 35°C (59 to 95°F) and object
temp. above 0°C (32°F)]
Measurement functions Spot
Box with max./min
Measurement correction Emissivity; matt/semi-matt/semi-gloss + custom value
Reflected apparent temperature
Atmospheric compensation
Image Storage
Storage media Internal memory and onboard FLIR Ignite cloud connectivity (with Wi-Fi)
Image storage capacity >5000 images
Image file format Standard JPEG, 14-bit measurement data included
Communication & Connectivity
Wi-Fi 802.11 a/ac/b/g/n (2.4 and 5 GHz)
USB USB 2.0, Type-C connector
Bluetooth® PAN
Image upload Directly upload images to FLIR Ignite cloud library and services
Additional Information
Battery type Rechargeable built-in Lithium-ion battery
Battery operating time 4 hours
Charging system USB-C (1 A)
Charging time 2 hours
External power operation 5 V, USB-C
Operating temperature range -10 to 50°C (14 to 122°F)
Storage temperature range -40 to 70°C (-40 to 158°F)
Encapsulation Camera housing and lens: IP54 (IEC 60529)
Drop test Designed for 2 m (6.6 ft)
Weight (including battery) 0.19 kg (0.42 lb)
Size (L × W × H) 138 × 84 × 24 mm (5.4 × 3.3 × 0.94 in)
Tripod mounting (built-in) UNC ¼”-20
