The FLIR Scion OTM2/366 Outdoor Thermal Monoculars are available in two models that vary in regards to their lens sizes and subsequently their fields-of-view. For further information, please see the following table.
|Model Code||Model Name||Lens Size||Field of View|
|7TM-01-F230||FLIR Scion OTM266 Outdoor Thermal Monocular||18mm||24º x 18º|
|7TM-01-F240||FLIR Scion OTM366 Outdoor Thermal Monocular||25mm||18º x 13º|
Please note that FLIR Scion Outdoor Thermal Monoculars (60Hz) with 320 x 256-pixel detectors are available here.
These thermal optics feature a slender, durable design and a simple operating system and intuitive menus making them both simple- and easy-to-use. These FLIR Scion OTM2/366 Outdoor Thermal Monoculars can be operated using a single hand.
The rugged, IP67-rated housing protects the internal hardware components, such as the FLIR Boson core, from any potential damage that may be caused by the environment or the elements. The sophisticated processing capabilities of the FLIR Boson core, the monoculars’ 640 x 512-pixel detectors, 60Hz frame rate and high-definition displays all ensure that the user is able to view continuous, clear and sharp thermal images and videos in all light conditions. These instruments are able to provide the user with the same clarity and comprehensive awareness of his/her surroundings in conditions ranging from complete darkness to glaring light to lingering haze.
Furthermore, the GPS functionality of the FLIR Scion OTM2/366 Outdoor Thermal Monoculars ensures that thermal media can be geotagged.
Thermal footage and images may be saved to the FLIR Scion OTM2/366 Outdoor Thermal Monoculars’ integrated 2GB memories and can be transferred to a compatible instrument (for example a PC, smartphone or tablet) via Wi-Fi or Bluetooth. Moreover; the FLIR Scion OTM2/366 Outdoor Thermal Monoculars are able to accommodate a 128GB microSD card, allowing the user to extend the monoculars’ memories as necessary, thereby facilitating the capture of hours of thermal images and footage.
In addition to this, the FLIR Scion OTM2/366 Outdoor Thermal Monoculars feature several user-selectable thermal imaging colour palettes, ensuring that it can be tailored to the application, environment and/or the user's preferences. The FLIR Scion OTM2/366 Outdoor Thermal Monoculars includes the following colour palettes:
- White Hot
- Black Hot
- Iron Bow
- Graded Fire
Please see the video below for an overview of the FLIR Scion's colour palettes.
Additionally, the FLIR Scion OTM2/366 Outdoor Thermal Monoculars’ Picture-in-Picture Zoom allows the user to view points-of-interest in greater detail without losing the overall field-of-view.
The FLIR Scion OTM2/366 Outdoor Thermal Monoculars are sophisticated, slender and simple-to-use instruments capable of capturing crisp, clear and continuous 60Hz thermal images and footage in challenging outdoor environments. They are ideal for hunting and tracking applications; for further information regarding the FLIR Scion OTM2/366 Outdoor Thermal Monoculars, please see the following videos.
FLIR Scion OTM2/366 Outdoor Thermal Monoculars Key Features
- Available in two models that vary in regards to their lens sizes and FOVs
- Slender, durable design
- Simple operating system
- Intuitive menus
- Simple- and easy-to-use
- Single-handed operation
- Rugged, IP67-rated housing protects the unit from the environment and weather
- FLIR Boson core
- 640 x 512-pixel detectors
- Frame rate: 60Hz
- HD display
- View continuous, clear and sharp thermal images and footage in all light conditions
- Provides a comprehensive awareness of the user’s surroundings
- Suitable for use in complete darkness, glaring light and lingering haze
- GPS functionality for geotagging thermal media
- Integrated 2GB memory
- Transfer saved media to a compatible instrument via Wi-Fi or Bluetooth
- Able to accommodate an OPTIONAL 128GB microSD memory card
- Several user-selectable colour palettes: White Hot, Black Hot, Iron Bow, Rainbow, Graded Fire, and Lava
- Picture-in-Picture Zoom: view points-of-interest in greater detail without losing the overall FOV
- Sophisticated, slender and simple-to-use instruments
- Capable of capturing crisp, clear and continuous 60Hz thermal footage anf images in challenging outdoor environments
- Ideal for hunting and tracking applications
- Your Choice of FLIR Scion OTM2/366 Outdoor Thermal Monocular – 60Hz
FLIR Scion OTM2/366 Outdoor Thermal Monoculars Technical Specifications
|Specifications||Scion OTM266||Scion OTM366|
|Core Technology||BOSON 12 µm VOx Microbolometer|
|Detector Resolution||640 x 512|
|Lens System||18 mm||25 mm|
|Field of View (H × W)||24° × 18°||18° × 13°|
|Digital Zoom||1X | 2X | 4X | 8X|
|Refresh Rate||60 Hz|
|Internal Memory||2 GB Internal Storage / Optional microSD™ Card (up to 128 GB)|
|Eye Relief||16 mm|
|Display||Quad-VGA (1280x960) FLCOS|
|Temperature Imaging Modes (Thermal Palettes)||White Hot; Black Hot; Iron Bow; Rainbow; Graded Fire; Lava|
|Viewing Modes||Scouting, Picture-in-Picture, Navigation|
|Picture While Recording (PWR)||Yes|
|Auto Power OFF||Yes|
|USB Type||USB-C; Power In; Video Out; Video and Image File Transfer|
|Battery Life||Up to 4.5 hours at 20°c|
|Battery Type||6x CR123A 3V Lithium Battery|
|NFC (Near-Field Communications||Yes|
|Size||227 × 76.8 × 60.5 mm (9.4 × 3 × 2.4 in)|
|Weight||With Batteries: 452 g; Without Batteries 572 g|
|Color (Housing)||Green / Black|
|Mounting||¼-20 Tripod Mount / Docking Station|
|Manufacturer Part Code||7TM-01-F230|
