Mark-10 Series FS06 Tension and Compression Force Sensors (500 N - 2.5 kN) - Choice of Sensor

Mark-10 Series FS06 force sensors measure tension and compression forces. Designed to accommodate bulkier grips and fixtures. Ranges are available from 500 N to 2.5 kN, five options are available. Compatible with Models F105, F305, F505, and F505H.

With Plug & Test technology, all configuration and calibration data is saved within the sensor, allowing it to be calibrated on the test frame or off-site with a Mark-10 indicator (optional adapter: AC1083 required).

Key Features

• Measure tension and compression force
• Suitable for larger and heavier grips and fixtures
• Compatible with Model F105, F305, F505, and F505H test frames
• Member of the Plug & Test® family of interchangeable sensors and indicators (optional adapter AC1083 required)
• NIST-traceable certificate of calibration with data is included
• Mark-10 Warranty: 3 years
• Accuracy: ± 0.15% of full scale + indicator or test frame
• Safe Overload: 150% of full-scale
• Weight:
  • FS06-50 – FS06-200: 1.7 lb [0.8 kg]
  • FS06-300 – FS06-500: 1.9 lb [0.9 kg]

Product Range

• FS06-100 Force Sensor, 100 lbF / 1600 ozF / 50 kgF / 50000 gF / 500 N
• FS06-200 Force Sensor, 200 lbF / 3200 ozF / 100 kgF / 1000 N / 1 kN
• FS06-300 Force Sensor, 300 lbF / 4800 ozF / 150 kgF / 1500 N / 1.5 kN
• FS06-50 Force Sensor, 50 lbF / 800 ozF / 25 kgF / 25000 gF / 250 N
• FS06-500 Force Sensor, 500 lbF / 8000 ozF / 250 kgF / 2500 N / 2.5 kN
