Sonel MMR-630 Micro-Ohmmeter

SKU
MMR-630
Rating:
0%
(0)
£2,946.00 £2,455.00
Free UK Delivery* Delivery Options

UK - Zone 1 Orders

England, Wales & most of Scotland.

Free 3-5 Working Day1
Orders Over £99 & Selected Items

Economy 2-3 Working Day1
From £1.95

Tracked 2-3 Working Day
£4.95

Express Next Working Day
£7.95

Priority Next Working Day
£14.95 (Pre-Noon)
£19.95 (Pre-10:30am)

Saturday & Sunday
£14.95 (Pre-Noon)

UK - Zone 2 Orders

Highlands, Islands & Northern Ireland.

Free 3-5 Working Day1
Selected Items (Calculated at Checkout)

Economy 2-3 Working Day2
From £1.95

Tracked 2-3 Working Day
£9.95

International Orders

Delivery is calculated at checkout.


Note: Next day delivery is not guaranteed for orders placed after 3:00pm.

1, 2 See delivery page for more details.

Price Match Guarantee & Advice

Sonel's MMR-630 is the upgraded version of the Sonel MMR-620 with enhanced resolution.

A portable solution for measuring low resistance levels in many different applications, Sonel's MMR-620 includes multiple measurement modes, easy-to-configure testing procedures and delivers consistent, accurate results with low resolution.

The following measurement modes are available on the Sonel MMR-630 low resistance ohmmeter:

  • Normal Mode - standard insulation resistance test
  • Automatic Mode - as the test leads are connected to the object, the MMR-620 will automatically start the measurement with dual direction current flow and average result display
  • Continuous Mode - every 3 seconds for resistive objects or continuous measurement on inductive objects
  • Window Mode - set an upper/lower limit with display of average measurement result

All measurement results can be stored directly in the MMR-630's internal memory, with support for download to PC (requires Sonel's optional software package).

Sonel MMR-630 Micro-Ohmmeter Key Features

  • Measure low resistance levels on resistive and inductive objects
  • Max test current of 10A
  • Resistance range to 1999Ω
  • Enhanced resolution compared to the MMR-620
  • Automatic and manual selection of measurement range
  • Multiple measurement modes - normal, automatic, continuous and window
  • Built-in memory storage with space for 990 records and support for download to PC
  • Quick PASS/FAIL test function
  • Portable, lightweight design supplied with straps for hanging around the neck

What's Included?

  • Sonel MMR-630 Micro Ohmmeter
  • 2 x Test Leads (3m)
  • 4 x Crocodile Clips
  • 2 x Kelvin Vice
  • Carrying Case
  • Cable for Battery Charger
  • NiMH Battery Pack
  • RS232 Serial Communication Cable
  • 2 x Double Pin Kelvin Probes
  • Hanging Straps
  • User Manual
  • Calibration Certificate

Optional Accessories

  • WAPR0PE4EN - Sonel PE4 Software for Documentation of Electrical Measurements
  • WAPR0PE4SEN - Sonel Schematic Software for Creating Drawings and Diagrams
  • WAADAKEY1 - USB Key for Software
  • WAADAUSBRS232 - USB1.1/RS232 Adapter
  • WAZACKEL1 - Kelvin Vice with Cables
  • WAZASZ6 - External Battery Charger
Part CodeMMR-630

Sonel MMR-630 Technical Specifications

RangeResolutionCurrentVoltage for the Full ScaleAccuracy
0 to 999μΩ 0.1μΩ 10A 20mV ±(0.25% m.v. + 2 digits)
1.000 to 1.999mΩ 0.0001mΩ
2.00 to 19.99mΩ 0.001mΩ 200mV
20.0 to 199.9mΩ 0.01mΩ 1A
200 to 999mΩ 0.1mΩ 0.1A
1.000 to 1.999Ω 0.0001Ω
2.00 to 19.99Ω 0.001Ω 10mA
20.0 to 199.9Ω 0.01Ω 1mA
200 to 1999Ω 0.1Ω 0.1mA
