TPI 9080-Ex Intrinsically Safe Vibration Analyser (ATEX)
A simple-to-use vibration monitoring and analysis tool, the TPI 9080-Ex Intrinsically Safe Vibration Analyser automatically performs vibration analysis functions based on the machine running speed to help diagnose faults such as unbalance, misalignment, and looseness.
PASS Presents the TPI 9080 Vibration Analyser
Vibration signals, vibration frequency plots, and BDU readings are indicated on the 800-line FFT display, allowing you to take vibration measurements and monitor vibration severity and bearing conditions. VibTrend software can be used to trend data. The TPI 9080-Ex Intrinsically Safe Vibration Analyser also includes ISO built-in alarms and band filters:
- 1x Unbalance
- 2x Misalignment
- 3x Looseness
Data can be transferred to a PC using the TPI 9080-Ex Intrinsically Safe Vibration Analyser’s integrated USB docking station.
The TPI 9080-Ex Intrinsically Safe Vibration Analyser also includes an intrinsically safe cable-mounted accelerometer with a magnet as well as built-in Bluetooth communication which enables use with optional Bluetooth headphones for listening to bearing noise. Furthermore, an optional strobe attachment means you can determine machine speed.
Finally, the TPI 9080-Ex Intrinsically Safe Vibration Analyser is housed in a ruggedised IP67 case. It is an easy-to-use, economical yet dynamic maintenance tool suitable for hazardous environments. The TPI 9080-Ex Intrinsically Safe Vibration Analyser can maximise machine uptime and productivity while lowering repair/maintenance costs by finding faults before they become failures.
TPI 9080-Ex Intrinsically Safe Vibration Analyser (ATEX) Key Features
- A simple-to-use vibration monitoring and analysis tool
- Automatically performs vibration analysis based on the machine running speed
- Diagnose unbalance, misalignment, and looseness
- Displays vibration signals, vibration frequency plots, and BDU readings
- 800-line FFT display
- Take vibration measurements
- Monitor vibration severity
- Track bearing condition
- VibTrend software for trending data
- ISO built-in alarms and band filters for unbalance (1x), misalignment (2x), and looseness (3x)
- USB docking station
- Intrinsically safe cable-mounted accelerometer with magnet
- Built-in Bluetooth
- Use with optional Bluetooth headphones
- Optional strobe attachment for determining machine speed
- Rugged, IP67-rated casing
- Suitable for hazardous environments
- Maximise machine uptime and productivity
- Lower repair/maintenance costs
- Find faults before they become failures
What’s Included?
- TPI 9080-Ex Intrinsically Safe Vibration Analyser (ATEX)
- TPI A9093 Intrinsically Safe Accelerometer & Magnet
- TPI A9081 Docking Station with USB Cable
- TPI A9083 VibTrend Standard Software
- Carrying Case
TPI 9080-Ex Intrinsically Safe Vibration Analyser Technical Specifications
| Size | 200 mm x 60mm x 26mm |
| Weight | 280g (not including magnet) |
| Water, Sand & Dust | IP67 Waterproof |
| Operating | (-20°C ≤ Ta ≤ +40°C) |
| Storage | -20°C to 70°C (-4°F to 158°F) |
| Power supply | 2 x AA batteries (Energizer L91) |
| Battery life | 2-year standby, 1,500 measurements, or approximately 50 hours of normal use |
| Frequency range | ISO: 2/10Hz – 1kHz g: 2Hz – 10kHz |
| Frequency resolution | 100 / 800 lines |
| Displayed amplitude units | Acceleration in g Velocity in inches per second or mm per second Bearing damage in BDU (bearing damage units) |
| Displayed Frequency Units | Hertz (Hz), CPM, or RPM |
| Input range | +/- 60 g |
| Dynamic range | 96 dB (0.01g resolution) |
| Auto set up of VA bands | True |
| Accelerometer connection | BNC connector cable with a removable magnet (1mV/g – 10,000mV/g) |
| Communication | Bluetooth or USB docking station and cable to PC; data integration using VibTrend software |
| Reading Storage | Unlimited assets/10 readings per asset with A9084 VibTrend Pro software as standard |
| SKU | TPI-9080-EX |
|---|---|
| Manufacturer Part Code | 9080-Ex |
| Country of Origin | South Korea |
