Fluke 8808A/TL Digital Multimeter 2x4W Test Lead Set

Perform 4-wire measurements with only two test leads
Two conductors per lead (one source and one measure)
Excellent resolution and accuracy

SKU

Fluke 8808A/TL

MPN

3111097

View Similar Products

Description Offers Technical Info Reviews

This set of test leads is the perfect accompaniment to Fluke's 8808A/TL Digital Multimeter, allowing you to complete comprehensive testing wherever and whenever you need to.

The pack is affordable, contains two X 4W test leads and works out of the box with the 8808a.

Call for Pricing

We require additional information

Call 01642 931 329 or complete the form:

How Can We Help? Got a question? Our team's ready to help. Looking for something specific? We carry thousands more products than you see here. Ask Our Experts A Question

Offers

Technical Information

Specification

Specifications

Display VFD multi segment display, dual readings
Display VFD multi segment display, dual readings
Resolution 5.5 digits
V dc Ranges: 200 mV to 1000 V Max. resolution: 1 uV Accuracy: 0.015 + 0.003
V ac Ranges: 200 mV to 750 V Max resolution: 1 uV Accuracy: 0.2 + 0.05 Frequency: 20 Hz to 100 KHz
Resistance 2x4 Wire: Yes Ranges: 200 Ω to 100 MΩ Max resolution: 1 mΩ Accuracy: 0.02 + 0.003
A dc Ranges: 200 µA to 10 A Max resolution: 1 nA Accuracy: 0.02 + 0.005
A ac Ranges: 20 mA to 10 A Max resolution: 100 uA Accuracy: 0.3 + 0.06 Frequency: 20 Hz to 2 kHz
Frequency Ranges: 20 Hz to 1 MHz Max resolution: 0.1 mHz Accuracy: 0.01 %
Math Functions dB/dBm: Yes
Advanced Functions Limit compare test, with pass and fail indicators
Interfaces RS-232, USB with optional adapter
Programming Languages/Modes Simplified ASCII, Fluke 45 remote command emulation
Weight 2.1 kg (4.6 lbs)
Size (HxWxD) 88 mm x 217 mm x 297 mm (3.46 in x 8.56 in x 11.7 in)
Safety Designed to comply with EN 61010-1:2001, ANSI/ISA 61010-1 (S82.02.01):2004, UL 61010-1:2004, AN/CSA C22.2 No. 61010.1:2004
