Free KANE 78 iD-Safe Personal CO Alarm & ID Holder (RRP £85.00), Kane KMCP35 Combustion Probe or Kane CP2S 10cm Flue Probe with Moulded Handle
Add this Kane FGA to your basket and automatically get a free Kane 78 iD-Safe Personal CO Alarm & ID Holder, Kane KMCP35 Combustion Probe or Kane CP2S 10cm Flue Probe with Moulded HandleT&Cs Apply.
Depending on the model selected, the Kane 458S Flue Gas Analyser Kit can be used for the following applications:
- Test domestic gas, oil, biomass and some commercial appliances
- Install and service domestic oil and gas appliances
- Safety checks (measure the CO in rooms and around appliances)
- Combustion performance checks
- Combustion efficiency checks
- Flue draught
There are five versions of the Kane 458S Flue Gas Analyser Kit available. They include the following items:
- Your Choice of Kane 458S Flue Gas Analyser
- Probe
- Pressure Connectors
- Charger
- Kane IRP-2 Infrared Printer
- Quick Reference Guide
- Calibration Certificate
- Carry Case
These kits differ in regards to the sensor combination of the included Kane 458S Flue Gas Analyser; please see the description and table below for further information.
Kane 458S Flue Gas Analyser Description
The Kane 458S Flue Gas Analyser is an ergonomic and easy-to-use FGA with an integrated wireless module capable of direct carbon monoxide and carbon dioxide measurements (model dependent). These flue gas analysers also include carbon monoxide (CO) and carbon dioxide (CO2) sensor protection, purge pump protection to prevent accidental damage to the CO sensor, and the latest upgradeable sensor technology.
As mentioned above there are five versions of the Kane 458S Flue Gas Analyser available. These differ in regards to their sensor combinations, please see the table below for further information.
SKU | Title | Gas Measurement |
KANE458SKIT | Kane 458S FGA Kit - CO & CO2 |
|
KANE458SKIT-OPT1 | Kane 458S FGA Kit - CO, CO2 & NO |
(Ideal for oil and biomass applications) |
KANE458SKIT-OPT2 | Kane 458S FGA Kit - CO2 & High-Range CO |
|
KANE458SKIT-OPT3 | Kane 458S FGA Kit - CO2, O2 & High-Range CO |
|
KANE458SKIT-OPT4 | Kane 458S FGA Kit - CO2, NO & High-Range CO |
|
The Kane 458S Flue Gas Analysers are also capable of measuring differential temperature and can calculate oxygen (O2), CO: CO2 ratio, excess air, and combustion efficiency. These flue gas analysers also include a structured commissioning test (for certifying new boilers according to Technical Bulletin 143) and a high-accuracy differential pressure meter (+/- 80mbar).
Using the Log & Print function pressure, let-by & tightness, combustion, temperature, CO build-up, and commission test reports can be sent to print wirelessly. Reports can be printed with the user's details via the included Kane IRP-2 Infrared Printer. The integrated wireless module also facilitates communication between the Kane 458S Flue Gas Analysers and Kane Gas Checker and Kane Live apps.
The Kane 458S Flue Gas Analysers also include a Data Hold function which will freeze the readings on the six-line display. Accessing the required measurement parameters and functions is easy due to the inclusion of a rotary dial.
Finally, the Kane 458S Flue Gas Analysers are compatible with natural gas, butane, LPG, light oil, wood pellets and propane, and are hydrogen (H2) ready (up to 20%).
The Kane 458S Flue Gas Analysers are versatile and simple-to-use FGA.
Kane 458S Flue Gas Analysers Key Features
- Ergonomic and easy-to-use FGA
- Integrated wireless module
- Capable of direct CO and CO2 measurements (model dependent)
- CO and CO2 sensor protection
- Purge pump protection to prevent accidental damage to the CO sensor
- Latest upgradeable sensor technology
- Five versions available with different sensor combinations
- Measure differential temperature
- Calculate oxygen (O2)
- Calculate CO: CO2 ratio
- Calculate excess air
- Calculate combustion efficiency
- Structured commissioning test
- High-accuracy differential pressure meter (+/- 80mbar)
- Log function
- Print function
- Log & Print function: print pressure, let-by & tightness, combustion, temperature, CO build-up and commission test reports
- Wirelessly print reports with the operator’s details using the Kane IRP-2 Infrared Printer
- The wireless module enables communication with the Kane Gas Checker and Kane Live apps
- Data Hold function
- Easy-to-use rotary dial
- Compatible with natural gas, butane, LPG, light oil, wood pellets and propane
- Hydrogen (H2) ready – up to 20%
- Versatile and simple-to-use FGA
What’s Included?
- Your Choice of Kane 458S Flue Gas Analyser
- Probe
- Pressure Connectors
- Charger
- Kane IRP-2 Infrared Printer
- Quick Reference Guide
- Calibration Certificate
- Carry Case
Please Note: Our 14-day money-back guarantee for flue gas analysers only applies if the tester is found to be faulty. This is due to the product being made to order by the manufacturer.
Kit Comparison
The Kane 458S Flue Gas Analyser is available as a standard instrument or as part of a Kit, Pro Kit, CPA1 Kit or Oil Kit. The table below offers an overview of the items included with each of these options.
Standard | Kit | Pro Kit | CPA1 Kit | Oil Kit | |
Kane 458S Flue Gas Analyser | X | X | X | X | X |
Probe |
X | X | X | X | X |
Pressure Connectors |
X | X | X | X | X |
Charger |
X | X | X | X | X |
Quick Reference Guide |
X | X | X | X | X |
Calibration Certificate |
X | X | X | X | X |
Kane IRP-2 Infrared Printer |
- | X | X | X | X |
Kane KAL1 Air/ Liquid Probe |
- | - | X | X | - |
Kane GLD450 Plus Gas Leak Detector |
- | - | X | X | - |
Kane ASP2 Appliance Sampling Probe Kit |
- | - | - | X | - |
2x Kane KPCP Pipe Clamp Temperature Probes |
- | - | X | X | - |
Pressure Connection Hose |
- | - | X | X | - |
Oil Pressure Test Set |
- | - | - | - | X |
Carry Case | X | X | X | X | |
Notes | X = Included | ||||
- = NOT Included |
SKU | KANE458S-KIT |
---|
