Pfisterer Voltage Detector KP-Test 5L, 20 - 36 kV
Free PASS Football (Spend £250+)
- 00107 Model
- Self-test at switch-on
- Double signalling
SKU
930210001-00107
MPN
930210001-00107
The Pfisterer KP-Test 5L is suitable for medium-voltage overhead lines. Designed for a nominal voltage range of 20–36 kV and operating at 50 Hz. It measures just 345 mm without insulating poles and is type-tested to IEC 61243-1.
The KP-Test 5L features a self-test function that activates at switch-on, bright LEDs, and an audible signal. The device’s high resistance to interference fields further guarantees accurate readings in the presence of surrounding electrical activity.
Key Features
- Double signalling
- Integrated audible signal for reliable voltage tests even in a noisy environment
- Extremely bright LEDs in a clear layout to prevent confusion
- Maximum resistance to interference fields
- Self-test at switch-on
- Can be used in rain and snow
KP-Test 5 - Reliable voltage detectors from PFISTERER
Offers
Free PASS Football (Spend £250+)
Automatically adds to your basket when the total exceeds £250+ (ex VAT). Limited Stock. More details here.
Technical Information
Specification
| Nominal Voltage | 20 - 36 Un (kV) |
|---|---|
| Nominal Frequency | 50 fN (Hz) |
| Suitable Bag | A4 |
| Suitable Case | K1 |
| Voltage Type | AC |
| Area of Application | Overhead Line |
| Type of Device | separate |
| Climate Class | W, N |
| Design | outdoor |
| Power Supply | 2 x alkaline batteries |
| Type | KP-Test 5L |
| Type Tested According to | IEC 61243-1 |
Additional Information
SKU
930210001-00107
Manufacturer Part Code
930210001-00107
Country of Origin
Germany
Pfisterer Voltage Detector KP-Test 5L, 20 - 36 kV
£499.00
£598.80 inc vat
£499.00
£598.80 inc vat
