Klauke EKM 60/22-L Battery Powered Hydraulic Crimping Tool
- 6 - 300 mm²
- Optional, L Dies, R Dies, or L-BOXX sets
- One-button operation
SKU
KL-EKM6022L/KITS
The Klauke EKM6022L has a large crimping range of up to 300 mm2 and an Automatic Retract Stop (ARS) function. The ARS function delivers positional control when making multiple crimpings. The slim crimping head makes the instrument an ideal solution when working in space-critical scenarios.
Key Features
- Suitable for interchangeable dies, series 22, narrow crimping
- Closed crimping head, flip top style, rotatable
- Electronic control and monitoring of crimping operation
- Integrated pressure measurement with visual and audible signals in case of failure
- Evaluation function using optical interface and USB adapter
- One-button operating concept for controlling all tooling functions
- Ergonomic 2-component plastic housing with soft linings for comfortable and safe one-hand operation
- Balanced centre of gravity for easy handling and effortless operations
- LED for workplace illumination
- High-performance 18V Lithium-ion battery with high capacity and extremely short charging time
- High-performance motors for maximum operating speed
- Quick motor stop for high user safety
- Automatic retraction when crimping is complete
- Manual retract in case of need
- Automatic retract stop (ARS) for positioning control in case of multiple crimpings
- Multi-function LED for maintenance control, charge level indicator of the battery and data transmission via USB adapter
- Environmentally-friendly hydraulic oil, quickly biodegradable
What's Included?
- Battery powered hydraulic crimping
- Battery 18 V / 1.3 Ah, Li-Ion (23.4 Wh)
- Quick-charger for 18V Li-Ion batteries, 230 V
- Plastic case
- Optional L-BOXX, L die set, or R die set
Product Range
- Klauke EKM6022L Battery Powered Hydraulic Crimping Tool
- Klauke EKM6022LSETL Battery Powered Hydraulic Crimping Tool & L Die Set
- Klauke EKM6022LSETR Battery Powered Hydraulic Crimping Tool & R Die Set
- Klauke LBOXXEKM6022L Battery Powered Hydraulic Crimping Tool & L-BOXX
Technical Information
Specification
| Crimping Force | 60 kN |
|---|---|
| Stroke | 17.5 mm |
| Crimping Range | 6 - 300 mm2 |
| Crimping Cycle | 2 s (for ARS) to 5 s (depending on cross-section) |
| Number of Crimps | approx. 150 - 200 at 150 mm² Cu DIN |
| Battery Voltage | 18 V |
| Battery Capacity | 1.3 Ah, Li-Ion |
| Charging Time | 15 minutes |
| Weight incl. Battery | 3.0 kg |
| Ambient Temperature | -10°C to +40 °C |
